Gaggenau AC462181

Vario modular ceiling ventilation 400 Series

AC 402

- It integrates perfectly with

the kitchen environment, disappearing into the

ceiling.

- Ceiling ventilation system

modular in infinite combinations

according to specific requirements.

- Extraction system for the entire

kitchen environment.

- Without motor, can be combined with

Gaggenau BLDC motors.

- Patented perimeter suction

high efficiency.

- Perimeter filters with smooth surface

and easy to clean.

Performance

Power level dependent on the

Gaggenau motor used.

Features

Design possibility with or

without light modules.

Perimeter extraction filters washable

dishwasher-safe.

Frame for installation (fixing elements

fixing elements not included).

Cylindrical duct DN 150.

Consumption values

Referring to a configuration

with AR 400 142.

Energy efficiency class B in

a scale of energy efficiency classes

energy efficiency classes from A++ to D.

Energy consumption 60.6 kWh/year.

Suction efficiency class A.

Lighting efficiency class E.

Filter efficiency class B.

Sound level min. 50 dB / max. 65 dB

at normal intensity.

Mounting precautions

Can be considered as a centre of

extraction for the entire room

kitchen if the distance to the worktop

is greater than 120 cm.

The right ratio between the power of the

motor and the volume of the kitchen

must be between 10 and 12.

Pay attention to the possible

configurations, motor groups and

related dimensions.

For extraction/

recirculation operation, please refer to the different

motors available.

Maximum 3 filter modules can be connected to the

AR 400 142 motor.

Always provide accessibility to the

selected motor.

In extraction installation, avoid

the narrowing of the ducting and

creation of excessively tight bends.

If installed in extraction mode

provide a safety switch

in case of an open-flame device with

open flame with a ventilated chimney (e.g.

chimney).

For recirculation operation refer

refer to the dedicated modules.
