Induction plan
Total number of cooking areas: 5
COTTURAL ZONE INDUSTRY
Selected zone indicator
Left front: Ø 17.5 cm, 1.30 kW - 1.40 kW
Left posture: Ø 21.5 cm, 2.30 kW - 3.00 kW
Central: Ø 26.5 cm, 2.30 kW - 3.00 kW
Right rear: Ø 21.5 cm, 2.30 kW - 3.00 kW
Front right: Ø 17.5 cm, 1.30 kW - 1.40 kW
Auto-stop in case of overheating
Minimum diameter indicator of use
Automatic adjustment to the diameter of the pot
FORNO PRIMARY:
5 cooking functions
Net volume of cavity: 61 l
Cooling system: Tangential
Display: electronic 5 keys
Fine cooking indication
Cleaning system: Vapor Clean
Temperature from 50° to 260 °C
Light on the door opening
1 halogen lamp, power 40 W
Metal frames, 4 cooking levels
N° thermoreflective glass: 3
Removable inner glass
OTHER:
Grille insert bacinella: 1
Grill oven with stop and stop: 2
SECONDARY FURNACE:
6 cooking functions
Net volume, second cavity: 61 l
Cooling system: Tangential
Temperature from 50° to 260 °C
Light on the door opening
1 halogen lamp, power 40 W
Metal frames, 4 cooking levels
N° thermoreflective glass: 3
OTHER:
Grille insert bacinella: 1
Grill oven with stop and stop: 2
OTHER:
1 cooking function
Cooling system: Tangential
Temperature from 50° to 260 °C
1 incandescent lamp, power 25 W
Type: Electric
Metal plates, 2 cooking levels
N° thermoreflective glass: 3
OTHER:
Grill oven with stop and stop: 1
Cassetto
TECHNICAL DATA
Energy Efficiency Class A
Current: 53 A
Frequency: 50/60 Hz
Voltage: 220-240 V
Voltage 2 (V): 380-415 V
Electrical connection data: 19500 W
