Induction plan
Total number of cooking areas: 5
COTTURAL ZONE INDUSTRY
Left front: Ø 14.5 cm, 1.40 kW - 2.20 kW
Left posture: Ø 18.0 cm, 1.85 kW - 3.00 kW
Central: Ø 27.0 cm, 2.60 kW - 3.70 kW
Right rear: Ø 21.0 cm, 2.30 kW - 3.70 kW
Front right: Ø 14.5 cm, 1.40 kW - 2.20 kW
Selected zone indicator
Auto-stop in case of overheating
Minimum diameter indicator of use
Automatic adjustment to the diameter of the pot
FORNO PRIMARY:
4 4
9 cooking functions
Net volume of cavity: 61 l
Cooling system: Tangential
Display: Touch
Cleaning system: Pyrolysis
Start and end cooking indication
Temperature from 50° to 280 °C
Light on the door opening
1 halogen lamp, power 40 W
Metal frames, 4 cooking levels
N° thermoreflective glass: 4
OTHER:
Grille insert bacinella: 1
Grill oven with stop and stop: 1
Grill for Wok
SECONDARY FURNACE: 4
6 cooking functions
Net volume, second cavity: 35 l
Cooling system: Tangential
Start and end cooking indication
Temperature from 50° to 250 °C
Light on the door opening
1 incandescent lamp, power 25 W
Metal frames, 4 cooking levels
Type: Electric
N° thermoreflective glass: 3
OTHER:
Bacinella allforno: 1
Grille insert bacinella: 1
Grill oven with stop and stop: 1
Cassetto
TECHNICAL DATA
Energy Efficiency Class A
Current: 23 A
Frequency: 50/60 Hz
Voltage: 220-240 V
Voltage 2 (V): 380-415 V
Electrical connection data: 12500 W
EAN Code: 8017709256777
