Flex Induction cooktop
400 Series
VI 422
-- Flex function for combining
rectangular cooking zones.
-- Free positioning of pots and
pans within the cooking zones.
cooking zones.
-- Frying Sensor for precise temperature control
precise temperature control during frying.
frying.
-- Easy control of all functions
functions thanks to the two-colour display
coloured display indicators.
-- Solid stainless steel control knob.
stainless steel control knob.
-- Frameless for flush top installation.
without frame for flush top installation.
-- Suitable for combination with VL 410.
Cooking zones
2 Flex Induction zones each of
20x24 cm (2200 W, with booster 3700
W) when combined they reach
size 40x24 cm (3300 W, with booster 3700 W).
booster 3700 W).
Operation
Steel knobs with ring
and silkscreen printing for cooking zones and
cooking zones and power levels.
Electronic power control with 12
levels.
User-friendly control with 2-colour display
colours (white/orange).
Features
Flex function for cooking zones
rectangular cooking zones.
Frying sensor.
Booster function.
Chronometer.
Programmable cooking time.
Options menu.
Power management function:
electronic regulation and limitation
of power consumption according
the need.
Possibility of hood control
(with compatible model).
Home Connect
Integrated digital services (Home Connect)
with the wireless home network via WiFi.
The operation of Home
Connect Wireless via WiFi depends
on the availability of the Home Connect service
Connect service in each country.
For more information visit
www.home-connect.com.
Security
Operation indicator light.
Pan recognition system.
Residual heat indication.
Automatic safety shutdown.
Assembly precautions
It is advisable to align knobs and
cooking zones.
If the thickness is greater than 23 mm
refer to the technical drawing regarding
on the installation of the knobs,
(provide a recess in the
rear).
The load-bearing capacity and stability, in particular
in the case of thin worktops, must
be supported by appropriate
substructures. Take into
consideration of the weight of the appliance
and additional loads.
Additional installation instructions
flush:
Installation is possible in floors made of
stone, synthetic or solid wood.
The thermal resistance
thermal resistance and watertightness of the edges
of the notch. Regarding
other materials, please consult the
manufacturer of the worktop.
The groove must be continuous and
uniform, so as to ensure the correct
positioning of the unit
on the gasket. Do not use a
discontinuous coating.
The width of the joint may vary
due to dimensional tolerances of the
combinations and the notch on the surface
working surface.
If several appliances are installed in
individual niches, provide a space of
at least 50 mm between the niches.
Only to be used with pans
ferromagnetic pans.
The appliance is equipped with springs
fixing springs that lock the top after
insertion from above.
Appliance weight 10 kg.
Connection values
Total consumption 3.7 kW.
Connection cable length 1.5 m
without plug.
