Description
Structure 8 SteelTM: steel tank, steel inner door, steel spraying arms, stainless steel filters,
stainless steel spray pipes, nylon coated steel grids, steel feet and external steel base
Circular pump and exhaust pump equipped with extra durable and silent induction engines
High-definition FFSTN display for easy reading
Performance
Super Cleaning SystemTM: Intensive prewashing, no hand prewashing
9 SprayTM system, designed to reach every corner of the dishwasher
Power Zone, set for cleaning pots and pans or bottles and pots; it is also possible to turn off
Turbo Combi DryingTM: Assisted drying with automatic open door drying, which eliminates all
moisture
Quality test: 12,500 hours, 280 cycles per year (20 years of domestic use)
Programs, Modes and Options
9 programs: Eco, Intensive, Automatic, Fast, Time, Hygienizing, Rinse, Auto-cleaning, Anti-
smell
Washing temperatures: from 51 to 70 °C
2 modes: Quick, Night
2 options: Automatic opening at the end of the cycle, Departure delayed (1-24 h)
Comfort / Safety
Status LightTM: indicates the progress status of the program
Aqua SafeTM system: guarantees protection from water leaks.
Easy installation: frontally adjustable door springs and feet
Cetelli
Upper basket for cutlery: removable and adjustable in height
Upper basket: height adjustable, 2 shelves for wine glass
Lower basket: adjustable supports for plates, removable cutlery basket
Simultaneous access to multiple baskets for optimum loading and unloading flexibility
Dimensions
Equipment Size (A/L/P): 859-912 / 596 / 554 mm
Dimensions necessary for the collection (A / L / P): min. 860 / 600 / min. 555 mm
Electric cable length / Location: 1825 mm / Rear, right
Inlet tube length / Counterdado size* / Position: from 1625 mm / 3⁄4” / Rear left
Exhaust Pipe Length / Exhaust Diameter / Position: 1515 mm / 19.5 mm / Rear left
Door length / Rotating point: 700-800 / 710 mm
Energy label EU
Energy efficiency class: A
Energy consumption for 100 cycles (kWh): 54
Covers: 14
Water consumption (liter/cycle): 9.2
Rumourity (dB(A) re 1 pW): 42
Technical data
Electrical connection: 1.9kW / 220–240V / 50Hz / 10A
Water pressure: 0.03–1.0Mpa
