Family: Kitchen Category: 90x60 cm Power supply Electric N° of furnaces: 3 Floor type Induction Type main oven Thermoventilated Type secondary oven Thermoventilated Cleaning system Vapor Clean Code EAN 801770919617
Color: Aesthetic cream: Victoria Design: Victoria Material Painted Door: With frame Panel finish
commands: Colored sheet Color flat: Black enamelled Handle Smeg Victoria Color knobs Steel Alzatina Yes
Display: electronic 5 keys Type glass Black Color handle: Brushed stainless steel knobs Smeg Victoria N° knobs: 9
Anthracite Chocolate Traditional Cooking Functions Static, Thermal-ventilated, Turbo, Eco, Strait Grill, Wide Grill, Ventilated Wide Grill, Ventilated Base Cleaning Functions Vapor clean Other functions: Freezing time PROGRAMMES / FUNCTIONS FORNO SECONDARY
N° cooking functions second cavity: 1 Traditional cooking functions second cavity: Thermo-ventilated
PROGRAMMES / TERMS FORNO
Number of functions: 1
OPINIONS
Option Lock Commands: Yes
MAIN FORCE OPTIONS
Time programmer: Yes Sound alarm of end cooking: Yes Minimum temperature: 50 °C Maximum temperature: 260 °C
OPTIONS FORCE
Minimum temperature: 50 °C Maximum temperature: 245 °C
TERMS FORCE
Minimum temperature: 50 °C Maximum temperature: 260 °C
TECHNICAL SPECIFICATIONS
Total number of cooking areas: 5 Position 1st area: Front left position 2nd area: Rear left position 3rd
area: Central • Location 4th area: Rear right Position 5th area: Front right Type 1st area: Induction -
Single Type 2nd area: Induction - Single Type 3rd area: Induction - Single Type 4th area: Induction - Single
Type 5th area: Induction - Single Size 1st area: Ø 18.0 cm Size 2nd area: Ø 21.0 cm Size 3rd area:
Ø 27.0 cm Size 4th area: Ø 18.0 cm Size 5° area: Ø 21.0 cm Power 1st area: 1.30 kW Power zone 2nd:
2.30 kW 3rd area power: 2.30 kW 4th area power: 1.30 kW 5th area power: 2.30 kW Booster 1st area power: 1.40
kW Power booster 2nd area: 3.00 kW Power booster 3° zone: 3.00 kW Power booster 4th area: 1.40 kW Power
booster 5° zone: 3.00 kW Auto-stop in case of overheating: Yes Automatic adjustment to the diameter of the pot: Yes
Minimum diameter indicator of use: Yes Selected zone indicator: Yes
TECHNICAL FEATURES
Net volume of cavity: 61 l Gross volume of the first cavity: 70 l Cavity material: Ever Clean enamel Number of shelves: 4
Type of shelves: Telai N° of lights: 1 Type of lights: Alogenes Light power: 40 W Number of fans: 1 Programming Options
cooking time: Start and end Door opening: Flag opening: Yes Removable door: Yes Internal door
all-glass: Yes Removable internal glass: Yes Number of oven doors: 3 N° thermoreflective glass: 1 Safety thermostat: Yes Cooling system: Tangential • Type grill: Electric Grill swivelling: Yes Grid resistance - Power: 1700 W
Grid resistance - Power: 2700 W Sole resistance - Power: 1200 W Sky resistance - Power: 1000 W
Circular resistance - Power: 2000 W Temperature regulation: Electronics TECHNICAL FEATURES FOR SECONDARY
Net volume, second cavity: 62 l Cavity material: Ever Clean enamel Number of shelves: 9 Type of shelves: Telai • No. of lights: 1
Type of lights: Alogenes Light power: 40 W Door opening: Flag opening: Yes Removable door: Yes
Inside door: Yes Removable internal glass: Yes Number of baked goods: 2 N° thermoreflective glass: 1 Thermostat
safety: Yes • Cooling system: Tangential Type: Electric Temperature Adjustment: Electronics
TECHNICAL FEATURES
Net volume of the third cavity: 36 l Gross volume of the third cavity: 41 l Cavity material: Ever Clean enamel No
shelves: 2 Type of shelves: Telai N° of lights: 1 Type of lights: Alogenes Light power: 40 W Door opening: Tipping door
removable: Yes Internal door window: Yes Removable internal glass: Yes Number of oven doors: 3 N° thermoreflective glass:
1 Safety thermostat: Yes Cooling system: Tangential Type: Electric Grill swivelling: Yes
wide grill - Power: 2700 W Temperature adjustment: Electronics
PREVENTIONS / ENERGY ETICHET
Energy efficiency class: In Power consumption per cycle in forced convection: 2.77 MJ Energy consumption per cycle in
forced convection: 0.77 KWh Energy consumption per cycle in natural convection: 3.42 MJ Energy consumption per cycle in
natural convection: 0.95 KWh Energy consumption zone 2: 182.6 Wh/Kg Energy consumption zone 3: 142 Wh/Kg
Energy consumption zone 4: 176.7 Wh/Kg Energy consumption area 5: 182.6 Wh/Kg
PREVENTIONS / ENERGY ETICHET - SECOND CAVITY
Energy efficiency class, second cavity: B Power consumption per cycle in forced convection, second cavity: 3.49 MJ Power consumption per cycle in forced convection, second cavity: 0.97 KWh
ELECTRICAL COLLECTION
Electrical connection data 19400 W Voltage: 220-240 V Voltage 2 (V) 380-415 V Frequency: 50/60 Hz
Power cord length: 150 cm
GAS COLLECTION
LOGISTICS INFORMATION
Product width (mm): 900 mm • Product height (mm) 900 mm Product depth (mm): 600 mm Weight
gross (kg) 118,600 kg Net weight (kg): 108,200 kg
