General
Number of zones: 4
9 levels of power and booster
Ceramic glass with rounded corners (4 mm radius)
Features
4 Bridge ™ inductors that can be united in 2 areas for cooking with pans and large pots
Easy Slide ™ control, allows you to control all the inductors easily
Pause function: by pressing the pause button, all active areas are regularized at a low level of
Temperature and timers lock
Children lock, prevents you from unintentionally change the settings
Timer, usable as a contaminated or countdown.
Performance
Left Front: Bridge ™ Zone, 2.1 kW (Boost 3 kW), 190 x 210 mm
Left behind: Bridge ™ area, 2.1 kW (Boost 3 kW), 190 x 210 mm
Front right: Bridge ™ area, 2.1 kW (Boost 3 kW), 190 x 210 mm
Right Right: Bridge ™ Zone, 2.1 kW (Boost 3 kW), 190 x 210 mm
Size
Product (L x P x a): 600 x 520 x 54/50 mm
Hole for installation in support (L x p x a): 560-562 x 490-492 x 40 mm
Hole for wired installation: refer to the built-in scheme and the installation manual
Technical data
Electric cable: Not present, to be sized based on the absorption and length of the cable itself
Voltage: 220-240 V
Frequency: 50-60 Hz
Maximum absorption: 7.4 kw
