Glass milk container up to 0.7 liters.
Removable container for 400 g of beans with lid saves aroma.
2.4 litre removable water tank.
Water pump with pressure of 19 bar.
Electronic indicator of replacement of cleaning and descaling cartridges and water filter.
Electronic control of the filling level of the collection tank and container for coffee residues.
Integrated and soft lighting for a perfect presentation of every single drink.
Tip: to save energy, the device passes
automatically at standby mode after about 30 minutes. This
time interval can be changed in the basic settings.
Selected digital services (Gaggenau Home Connect)
Coffee World: Wide choice of coffee specialties from all over the world.
Remote control and monitoring.
Playlist function.
Security
Children’s safety to avoid accidental ignition or operation of the appliance.
To protect the appliance from any damage caused by water, the
tap water connection is equipped with aqua stop safety system.
Cleaning
Fully automatic cleaning and descaling with cartridges. Possibility to switch to
manual cleaning and descaling with tablets.
Automatic steam cleaning of the milk system after each milk-based drink.
Holiday mode to prepare the appliance for long periods of inuse or transport.
Vacuum grinding function to eliminate coffee residues from the system when changing type of bean.
Removable dispensing unit.
Coffee residue container and dishwasher safe tray.
Dishwasher-washable beverage dispenser.
Washable milk container in the dishwasher.
Design notes
Design the niche without back wall.
Non-reversible door hinge.
Ideal installation height from 95 cm to 145 cm (top edge of the niche bottom).
Dip from the front of the appliance to the 42 mm cabinet.
When designing a solution near a wall, pay attention to the opening door
side and minimum distance required from the wall.
Door opening angle about 110° - the distance from the wall must
to be at least 350 mm.
Door opening angle about 92° - the distance from the wall must
to be at least 100 mm (spare code n. 00 636 455).
It is possible to install directly over the drawer warmers.
Due to the highest housing (449 mm), each
combination with GC must be carefully planned.
For a perfect installation, we recommend the use of the entire surface intermediate shelf
GA 601 010 for a vertical combination with other devices.
The installation above a combined microwave oven is only possible with a standard furniture shelf. In this case, the use of
intermediate shelf GA 601 010 is not allowed.
The connection to the water network must always be accessible and should not be directly behind
the device.
Connection values
Total absorption 1.5 kW.
Connection cable 1.75 m with plug.
Inlet pipe 170 cm with attack
3/4” (26.4 mm), extendable.
